Ceramic Infrared Heating Elements

Ceramic infrared heating elements provide efficient, contactless heat transfer for industrial processes requiring fast response and uniform surface heating. They are widely used in drying, curing, thermoforming, packaging, and material processing applications where precise thermal control is essential.

Contact Us for Custom Solutions

For technical details, customized designs, and application-specific recommendations, please contact our engineering team. We will support you with the right ceramic infrared heating solution for your process..

Request a quote

Ceramic Radiant Elements

Reliable and High-Efficiency Solutions for Industrial Infrared Heating

Ceramic radiant elements are a proven and reliable choice for industrial infrared heating applications where stable performance, long service life, and uniform heat distribution are essential. As one of the most widely used infrared radiator technologies, ceramic heating elements are trusted across a broad spectrum of industrial and engineering processes.

These robust elements are particularly suitable for thermoforming, packaging, annealing, paint curing, printing, and a wide range of drying processes. By emitting long-wave infrared radiation, they ensure gentle yet effective heat transfer, minimizing thermal stress on materials while maintaining consistent process results.

Each ceramic infrared heating element is designed to operate at temperatures of up to 780 °C and emits infrared radiation within the 2–10 micron wavelength range, making it ideal for heating surfaces and materials efficiently. Standard electrical configurations include 230 V and 400 V, with power ratings typically ranging from 60 W to 1200 W, allowing easy integration into both small-scale and high-capacity systems.

The long-wave ceramic infrared elements manufactured by Caldor Heat Engineering SRL are available in trough, hollow, and flat designs, enabling optimal adaptation to different machine layouts and heating requirements. All elements are CE marked , ensuring full compliance with international safety, quality, and reliability standards.

Designed for continuous industrial operation, Caldor’s ceramic radiant elements deliver efficient infrared heating with predictable performance, making them a dependable solution for modern production environments.

Additional Features of Caldor Ceramic Elements

Expand to view details
Standard & Custom Colors
Available in standard colors: white, yellow-green, and black. Custom color options can be produced based on your application needs and visual requirements.
Integrated Thermocouple Options
Optional integrated thermocouples for temperature monitoring and closed-loop control:
  • Type J
  • Type K
Custom Manufacturing for Your Brand
We provide custom manufacturing aligned with your brand specifications and visual identity, supporting OEM programs and private-label requirements.
Reflector Design & Production Services
We support your application with reflector engineering and production services, tailored to your heater geometry, target heating profile, and installation constraints.


Industrial Applications & Technology Overview

Diverse Industrial Applications
Our infrared heating solutions are applied across a wide range of industrial processes:
  • Annealing – controlled heat treatment for metals and engineered materials
  • Preheating & localized heating – preparing components for downstream operations
  • Drying & curing – painting, printing, coating, and finishing processes
  • Laminating & composite forming – precise thermal control for layered materials
  • Conveyor heating – integrated solutions for continuous production lines
  • R&D and prototyping – flexible systems for testing and product development
Who We Work With
We have experience delivering infrared and electric heating solutions for a broad range of industries:
  • Automotive
  • Aerospace & Defence
  • Construction and building materials
  • Food packaging
  • Consumer electronics and appliances
  • Glass and ceramics
  • Textiles and technical materials
Why Infrared Heating?
Infrared heating transfers energy directly into the material, without unnecessary heat loss to the surrounding air or machine structures. This results in:
  • Faster heat-up times
  • Higher energy efficiency
  • Clean, combustion-free operation
  • Improved process control and repeatability
  • Reduced overall energy consumption

These characteristics make infrared heating an ideal technology for modern, sustainable, and high-performance industrial manufacturing processes.

Ceramic Infrared Heating Technology

Ceramic Infrared Heating Elements

Typical Applications
Thermoforming, packaging, annealing, paint curing, printing, and industrial drying processes.
Infrared Performance
Long-wave infrared radiation for efficient, uniform, and contactless heat transfer.
European Manufacturing
Designed and manufactured in Romania by Caldor Heat Engineering SRL for industrial and OEM use.
General Technical Characteristics
Max operating temperature: up to 780 °C Infrared wavelength range: 2–10 µm Standard voltages: 230 V / 400 V Power range: 60 W – 1200 W CE marked (product range)
Industrial Heating Solutions by Caldor
Caldor Heat develops ceramic infrared heating solutions tailored to each application, ensuring optimal integration into industrial production lines and consistent thermal performance.
Temperature Control & System Integration
Infrared systems can be combined with suitable control units for precise temperature regulation, energy optimization, and safe operation within automated production environments.
Custom Manufacturing & OEM Capabilities
Custom dimensions, colors, integrated thermocouples, branding options, and reflector design services are available to support OEM and project-specific requirements.
Ceramic Full Trough Infrared Heating Element (245 × 60 × 35 mm)
Electric Power 250 W 400 W 500 W 650 W 1000 W 1200 W
Power density, W/cm² 1.5 2.3 2.9 3.8 5.9 7.5
Maximum surface temperature (1), °C / °F 400 / 752 490 / 914 540 / 1004 600 / 1112 720 / 1328 720 / 1328
Specific surface radiation energy (1), W/cm² 1.12 1.85 2.38 3.16 5.29 –
Useful wavelength, µm 2.2 – 10.5 2.05 – 9.4 1.8 – 8.75 1.7 – 8.25 1.5 – 7.10 –
Max spectral radiation intensity wavelength, µm 4.4 3.8 3.4 3.1 2.9 –
Time needed to reach operating temperature (1), min 20 18 16 14 12 12
Emitter maximum temperature, °C / °F 750 / 1382
AC power supply (50 Hz), V 220 / 230
Operation mode Long term, under supervision
Radiating surface dimensions (mm / inch) 245 × 60 / 9.64 × 2.36
Estimated surface area of radiation, cm² / in² 170.9 / 2.65
Weight, g / oz 250 / 8.82

(1) Reached at ambient temperature from +18 °C to +25 °C

Ceramic Full Flat Infrared Heating Element – Hollow (245 × 60 × 36 mm)
Electric Power 250 W 400 W 600 W 800 W 1000 W
Power density, W/cm² 1.4 2.2 3.3 4.4 5.6
Maximum surface temperature (1), °C / °F 380 / 716 480 / 896 570 / 1058 650 / 1202 710 / 1310
Specific surface radiation energy (1), W/cm² 1.00 1.75 2.75 3.95 5.08
Useful wavelength, µm 2.25 – 10.8 1.95 – 9.3 1.75 – 8.4 1.65 – 7.7 1.5 – 7.15
Maximum spectral radiation intensity wavelength, µm 4.4 3.8 3.4 3.1 2.9
Time needed to reach operating temperature (1), min 20 18 16 14 12
Emitter maximum temperature, °C / °F 750 / 1382
AC power supply (50 Hz), V 220 / 230
Operation mode Long term, under supervision
Radiating surface dimensions (mm / inch) 245 × 60 / 9.64 × 2.36
Estimated surface area of radiation, cm² / in² 179.8 / 2.78
Weight, g / oz 230 / 8.11

* (1) Reached at ambient temperature from +18 °C to +25 °C

Ceramic Square Flat Infrared Heating Element (122 × 122 mm)
Electric Power 250 W 400 W 600 W 800 W 1000 W
Power density, W/cm² 1.4 2.2 3.4 4.5 5.6
Maximum surface temperature (1), °C / °F 380 / 716 480 / 896 570 / 1058 650 / 1202 710 / 1310
Specific surface radiation energy (1), W/cm² 1.00 1.75 2.75 3.95 5.08
Useful wavelength, µm 2.25 – 10.8 1.95 – 9.3 1.75 – 8.4 1.65 – 7.7 1.5 – 7.15
Maximum spectral radiation intensity wavelength, µm 4.4 3.8 3.4 3.1 2.9
Time needed to reach operating temperature (1), min 20 18 16 14 12
Emitter maximum temperature, °C / °F 750 / 1382
AC power supply (50 Hz), V 220 / 230
Operation mode Long term, under supervision
Radiating surface dimensions (mm / inch) 122 × 122 / 4.8 × 4.8
Estimated surface area of radiation, cm² / in² 178.6 / 2.77
Weight, g / oz 230 / 8.11

* (1) Reached at ambient temperature from +18 °C to +25 °C

Technical & Commercial Inquiries for Custom-Engineered Ceramic Infrared Heaters

Contact our engineering team to request detailed quotations and submit technical specifications for customer-oriented, application-specific ceramic infrared heating solutions. Designed for efficient infrared heat transfer, high operating temperatures, and long service life, our ceramic IR heaters are fully customizable to meet your exact industrial process requirements.
